Bandwidth:100 MHz
Sample Rate:2 GS/s
Channels:4 Channels
Memory Depth:2 Mpts per channel
Vertical Resolution:8 bits
Input Range:+/- 8 V
Trigger Modes:Edge, Pulse, Video, Pattern
Interface:GPIB, USB, Ethernet
The Tektronix 5440 Digital Storage Oscilloscope is a versatile tool designed for industrial control applications. Its robust design ensures reliable operation in demanding environments. With a bandwidth of 100 MHz and a sample rate of 2 GS/s, this oscilloscope provides detailed signal analysis capabilities.
The oscilloscope features four independent channels, allowing users to view multiple signals simultaneously. Each channel supports a memory depth of up to 2 million points, ensuring high-resolution captures even at high speeds.
Designed with user convenience in mind, the Tektronix 5440 includes a variety of trigger modes including Edge, Pulse, Video, and Pattern. This ensures accurate signal capture under different conditions. The oscilloscope also supports multiple interfaces like GPIB, USB, and Ethernet, enabling seamless integration with other equipment and systems.
Built with high-quality components, the Tektronix 5440 delivers superior performance and longevity. Its compact form factor makes it easy to integrate into existing setups, saving valuable workspace.
In summary, the Tektronix 5440 Digital Storage Oscilloscope is an indispensable tool for engineers and technicians working in industrial control systems. Its advanced features, coupled with its ease of use and reliability, make it a top choice for professionals requiring precise signal analysis.
